<高低温试验箱
高低温试验箱又名环境试验机，实验各种材料耐热、耐寒、耐干、耐湿性能，适合电子、电器、通讯、仪表、车辆、塑料制品、金属、食品、化学、建材、医疗、航天等制品检验质量之用。
产品参数：
| 型号Modal | FSG-A-80 | FSG-A-150 | FSG-A-225 | FSG-A-408 | FSG--A-800 | FSG-A-1000 |
| 内部尺寸WxHxD（cm)intemalDimensions | 40x50x40 | 50x60x50 | 60x75x50 | 80x85x60 | 100x100x80 | 100x100x100 |
| 外部尺寸W*H*D(cm)ExtemalDimensions | 70x158x146 | 80x168x156 | 90x183x156 | 100x193x166 | 110x203x186 | 110x203x206 |
| 内箱体积inner chamber volume | 80L/升 | 150L/升 | 225L/升 | 408L/升 | 800L/升 | 1000L/升 |
| 温度范围Temperature Range | -70℃-+150℃1180)(A:-20℃ B:-40℃ C:-60℃ D:-70℃ |
| 湿度范围Humidity Range | 20%-98%R.H.(10%-98%R.H/5%-98%R.H为特热选用条件R.H is a speciai optional condition ) |
| 温湿度解析精度/均匀度 Analvtie Accuracy/evenness degree ofTemperatue and Humidity | ±0.1℃:+0.1%8.H.20℃:*3.0%AH |
| 升温/降温时间Temperafure Rising/Falling Time | 平均4℃/分钟:平约1.2℃分钟Approaimately4.0℃/minute: aporoximately1.2℃/minute |
| 内外部材质Inner and Outer Materials | 内箱为SU不情钢镜面板，外随为铁板高精密日本技术烤漆。The inside case for SU staintess steol mirror board. outside the box for iron planehigh orecision of jacanese technoloay finitn |
| 保温材质Insulation Materia | 耐高温高密度氯基甲酸乙酸泡沫绝缘体材料Resistan to high temperature, high density. formate chlorine, ethyt acetum foam insulation materiats |
| 冷却系统Cooling System | 风、水冷式单/双段压缩机Air.watercooling'double segmentcompresso |
| 保护装置Protection Devices | 无保险丝开关、压缩机过载保纳开关、高低压冷却液保护开关、过湿过温保护开关、保险丝、故障报警系统Fuse-free switch. overloading arotection switch for comoressor. high and low voltage coolant orolectionswitch,over-humidity and over-temperature protection switch. fuses. failure waming system |
| 配件parts | 观察窗。50mm测试孔，PL内部灯泡、隔断板，干温球炒网watching window.50mm testing hole. PL internal bulbs, partition plate, dry and wet baii gauze |
| 控制Scontrol panel | 德国西门于PLC或韩国TH-900CGerkanSiemens PLCorTH-900CKore8 |
| 压缩机Compressor | 法国“泰康”牌Fran/s“Tecumseh” |
| 电源Power | 1Φ220VAC±10%50/60H&3Φ380VAC±10%50/60Hz |
